SEBU8191-01 55
Maintenance Section
Engine Mounts - Inspect
g02775881
Illustration 52
Typical e xample
2. Remove the wing nut (1) and the cover (2).
3. Remove the filter elements (3) from the breather
body (5).
4. Clean the filter elements (3) and dry the filter
elements. Inspect the filter elements for damage
or deterioration. If necessary, replace the filter
elements.
5. Install the filter elements (3) to the breather body
(5).
6. Ensure that the seal in the cover (2) is free from
damage. If necessary, replace the seal.
7. Align the cover (2) with the dowel (4). Install the
cover to the breather body (5).
8. Install the wing nut (1). Tighten the wing nut
securely.
9. Restore the electrical supply to the starting motor.
i02415257
Engine Mounts - Inspect
Misalignment of the engine and the driven equipment
will cause extensive damage. Excessive vibration
can lead to misalignment. Excessive vibration of the
engine and the driven equipment can be caused by
the following conditions:
•
Improper mounting
•
Loose bolts
•
Deterioration of the isolators
Ensure that the mounting bolts are tightened to the
correct torque.
Ensure that the isolators are free of oil and
contamination. Inspect the isolators for deterioration.
Ensure that
the bolts for the isolators are tightened to
the correct torque.
Replace any
isolator that shows deterioration. For
more information, see the literature that is provided
bytheOEMoftheisolators.
i04631322
Engine Oil Filter (Auxiliary) -
Change
Note: Refer to the Operation and Maintenance
Manual, “Engine Oil Sample - Obtain” before
performing maintenance.
Change the Filter with the Engine
in Operation
Hot oi
l and hot components can cause personal
injury. Do not allow hot oil or hot components to
contact the skin.
g02775859
Illustration 53
Typ ical example
