28 User’s Handbook, TSL 4230, Issue 4
4016-E61TRS
How to clean the plug filter fitted in the oil gallery for the piston cooling jets
1 Remove the plug filter (A1).
2 Clean the filter using a suitable solvent, if necessary use compressed air to remove small particles from the
gauze.
3 Refit the plug filter (A1), complete with a new sealing washer, part number 036620 (A2), and tighten to a
torque of 70 Nm (50 lbf ft).
Caution: Use the oil priming sequence before the engine is run, see the OEM Application, Installation and
Commissioning Manual (TSL 4232).
