Design and Function
General
The Permobil C500 is a power wheelchair for outdoor and indoor driving intended
for persons with functional impairments.
The wheelchair consists of a chassis and a seat. The seat consists of the seat
frame, seat plate/backrest, armrest/legrest, seat lift/fixed seat and possible
accessories and additional options such as a headrest, calf rest, chest support, etc.
In these operating instructions, we have chosen to show the wheelchair with our
Corpus II seat. The management of the chassis and most of its functions are,
however, the same regardless of which seat model is selected.
Overview
1. Backrest 6. Front Wheel (drive wheel)
2. Control Panel 7. Rear Wheel
3. Seat 8. Chassis
4. Legrest 9. Armrest
5. Footplate
1
2
3
4
5
6
7
8
9
