Owner´s Manual Permobil C500 R-net Diagnostics
82
3. Diagnostic Text Definitions
Once a trip text and module have been established use the following definitions
to ascertain the possible cause and required corrective procedure.
Trip Text Referral Point
Joystick Error Refer to section 3.1
Low Battery Refer to section 3.2
High Battery Refer to section 3.3
M1 Brake Error Refer to section 3.4
M2 Brake Error Refer to section 3.4
M1 Motor Error Refer to section 3.5
M2 Motor Error Refer to section 3.5
Inhibit Active Refer to section 3.6
Jstick Cal Error Refer to section 3.7
Latched Timeout Refer to section 3.8
Brake Lamp Short Refer to section 3.9
Left Lamp Short Refer to section 3.10
Right Lamp Short Refer to section 3.10
L Ind Lamp Short Refer to section 3.11
R Ind Lamp Short Refer to section 3.11
L Ind Lamp Failed Refer to section 3.12
R Ind Lamp Failed Refer to section 3.12
DIME Error Refer to section 3.16
Memory Error Refer to section 3.17
PM Memory Error Refer to section 3.18
Bad Cable Refer to section 3.19
Bad Settings Refer to section 3.20
Module Error Refer to section 3.21
System Error Refer to section 3.22
Gone to Sleep Refer to section 3.23
Charging Refer to section 3.24
