Owner´s Manual Permobil C500 Design and Function
3636
Seat Control Panel
With this panel, the wheelchair’s electrical seat functions are controlled.
NOTE! The number of available functions and their position on the panel, can
vary depending on how your wheelchair is equipped.
1. Seat Lift
The seat is raised when the top part
of the seat lift button is pressed,
and lowered when the bottom part
of the button is pressed.
2. Backrest Recline
The backrest is tilted backwards
when the bottom part of the back-
rest angle button is pressed and for-
wards when the top part of the but-
ton is pressed.
3. Seat Tilt
The seat is angled backwards when
the bottom part of the seat tilt angle
button is pressed, and move for-
wards when the top part of the button
is pressed.
4. Legrest
The legrest moves forwards when
the top part of the leg support button
is pressed, and backwards when
the bottom part of the button is
pressed.
1 2 3 4
