Permobil C500 - Electrical System and Component Data

Electronics ............................C500/C500s
PM80/PM100
Control Panel
JSM-L 7key Pilot+
Batteries
Recommended Battery Type..Group 24, Gel
Battery Capacity ....................2x73 Ah
Charging Time ........................9 hour
Fuses......................................C500/C500s
Circuit Breaker ........................63A/80A
Charging Fuse ........................15A/15A
Electronics ............................C500/C500s
PM80/PM120
Control Panel
JSM-L-SV
Batteries
Recommended Battery Type..Group 24, Gel
Battery Capacity ....................2x73 Ah
Charging Time ........................9 hour
Fuses......................................C500/C500s
Circuit Breaker ........................63A/80A
Charging Fuse ........................15A/15A
ELECTRIC SYSTEM PILOT+ ELECTRIC SYSTEM R-net
Owner´s Manual Permobil C500
73
Technical Specifications
General
Name .............................................................................. Permobil C500/C500 Lowrider
Size and weight
Length..............................................................................49,5”
Width................................................................................25,5”
Height C500 ....................................................................52,5”
Height C500 Lowrider ....................................................47,5”
Smallest Transport Size, lxwxh C500 ..............................37,5x25,5x33”
Smallest Transport Size, lxwxh C500 Lowrider ..............37,5x25,5x32”
Weight incl. Batteries and Corpus-Seat ..........................350 lbs
Max. Battery Size ............................................................10,25x6,75x8,25”
Wheels
Tire Size, front..................................................................300 x 8
Tire Size, back ................................................................210 x 65
Max Air Pressure, front/back tires ..................................29 psi (200 kPa)
Performance
Range ..............................................................................19 - 25 miles
Minimum Turning Radius ................................................28”
Ability to Negoatiate Obstacles ......................................3”
Hill Climbing Capability, uphill ........................................12 degrees*)
Hill Climbing Capability, downhill ....................................12 degrees*)
Sideways Slope Capability..............................................10 degrees
Max Speed Forward ........................................................C500 C500s
5 mph 7,5 mph
Max Speed Backward, approx........................................2,5 mph 2,5 mph
*
)
Dynamic stability according to ISO 7176-2 = 6° .
DATA
