Owner´s Manual Permobil C500 Design and Function
26
Seat Lift
The Permobil C500 can be fitted with an electrically controlled seat height
adjuster. An actuator device which is controlled from the maneuvering panel
makes it possible to raise the seat up to 7 3/4” to adapt the height to tables,
benches, etc. If the seat lift is raised from its lowest position, the wheelchair's
maximum speed is reduced.
Seat Tilt
The Permobil C500 can be fitted with an electric seat tilt actuator adjuster, which
lets you adjust the angle of the seat. The electric seat tilt actuator is controlled from
the control panel or from the seat control panel.
Seat Lift Seat Tilt
User Weight over 220 Lbs.
If the user weight exceeds 220 Lbs. the wheelchair can be provided with safety inhibits on the seat-
ing system to secure the wheelchair's stability. These inhibits prevents the ability to tilt the back-
rest/seat tilt backward when the seat lift is raised from its lowest position, or driving the seat lift upp-
ward if the backrest is tilted backward more then 45 degres.
NOTE
