Owner´s Manual Permobil C500 Troubleshooting Guide
77
INDICATOR LIGHTS
Light 1 (red) slowly blinking.
CAUSE
The batteries need charging or there is a
bad connection to the batteries.
SOLUTION
Check the connections to the batteries.
If the connections are good, try charging
the batteries.
INDICATOR LIGHTS
Lights 1-7, 3 red and 4 orange, blinking
rapidly upon start-up and the wheelchair
can not be driven.
CAUSE
A joystick fault is indicated.
SOLUTION
• Make sure the joystick isn’t actuated at
switch-on, or
• Replace the Control Panel.
Low battery voltage
Open circuit, left drive motor
Short circuit left drive motor
Open circuit, right drive motor
Failure in wheel lock circuit
High battery voltage
CAUSE SOLUTION
Fault in electronics
Fault in the control panel
Charger connected
Short circuit right drive motor
Check the condition of the battery. Check the con-
nection between the battery and the control unit.
Check the battery and the connections between
the battery and the control unit.
Check the connections to the magnetic wheel
lock.
Check the contacts to the output stage. If the fault
persists, change the output stage.
Make sure the joystick isn’t actuated at switch-on,
change the control panel.
Remove the charging plug from the charging
socket on the wheelchair
Check the drive motor connections and cable.
Check the connection to the right drive motor.
Check the drive motor connections and cable.
Check the connection to the right drive motor.
1
Red
10
Green
9
Green
8
Green
7
Orange
6
Orange
5
Orange
4
Orange
3
Red
2
Red
EXAMPLE 1 EXAMPLE 2
