Permobil Explorer Mini - Maximum Speed Indicator; Horn Button

Explorer Mini Getting to know your wheelchair
3.4.4 Maximum speed indicator
Figure 15. Maximum speed indicator. A shows the
maximum setting. B shows the medium setting. C shows
the minimum setting.
The maximum speed indicator has five settings. The LEDs on the
speed indicator show the current maximum speed setting:
• When the fifth LED (A) is lit, the maximum setting is active.
• When the third LED (B) is lit, the medium setting is active.
• When the first LED (C) is lit, the minimum setting is active.
3.4.5 Horn button
Figure 16. Horn button.
Press the horn button to make the horn sound.
50
