Permobil Explorer Mini - Seat

Explorer Mini Getting to know your wheelchair
3.3.1 Seat
Figure 2. Adjustment range for the seat height.
The seat height has four different settings. If needed, the seat can be
removed.
For instructions on adjustments of the seat, see 4
Adjustments .
3.3.2 Table and backrest unit
Figure 3. Adjustment range for the table and backrest
unit.
The table and backrest are combined to one unit. This unit provides
ergonomic positions for sitting and standing. The height of the table
and backrest unit can be changed to ten different positions.
For instructions on adjustments of the table and backrest unit, see
4
Adjustments .
41
