Permobil Explorer Mini - Cushion; Removing the Cushion

Explorer Mini Adjustments
4.4 Cushion
4.4.1 Removing the cushion
The wheelchair has a removable cushion. There are four screws,
attached to the cushion, that hold the cushion in place.
Figure 39. Remove the screws from the attachment
points on the backrest.
1. Remove the four screws from the attachment points on the
backrest.
2. Remove the cushion from the backrest.
75
