Explorer Mini Adjustments
Figure 29. Prepare removal of the seat.
2. Remove the tightening knob (A) from the column.
3. Pull out the plunger knob (B).
Figure 30. Remove the seat from the column.
4. Push down the seat and slide it off the column.
