Changing the seat lift
Fitting
1. Place the seat lift in the mounting on the chassis.
2. Screw the seat lift in place at the bottom of the
mounting using screws, washers, ball bearings
and locking nuts.
3. Screw the seat lift in place in the rear mounting
with screws and locking nuts. Tighten the screws
properly.
4. Mount the seat lift motor at the very rear of the
seat lift. See page 21.
5. Connect the cables of the seat lift motor to the
jack panel.
6. Lift the batteries back onto the chassis.
Attach the battery connections, first the negative
poles and then the positive poles. See page 9.
7. Lift the seat and seat plate onto the seat lift.
Screw the two screws in place under the seat
mounting. See the figure to the right.
Tighten the screws properly.
8. Connect the seat's cable connection to the jack
panel. Tie the cables in place in the seat lift.
See the figure to the right.
9. Refit the cover. See page 7.
10. Switch on the main fuse/battery cut-out.
Mounting the seat lift
Fixing the cables
Mounting the seat
Mounting the seat lift
