Raising the seat lift
8
Cover (with fixed seat tube)
Removal
1. Loosen the rear Allen screws and tip the
seat forwards, see the figure to the right.
2. Unscrew the four screws which hold the
cover in place.
3. Lift off the cover.
NB. Be careful with the cable which goes
to the rear lights. Disconnect the contact
which is connected to the jack panel.
Fitting
1. Place the cover on the chassis after the
rear lighting cable has been connected to
the jack panel.
NB. The rear lighting cable must not be
pulled over any of the drive motors.
There is a risk that the cable will become
caught between the motor/brake and the
cover.
2. Screw down the four screws which hold
the cover in place.
3. Fold the seat down and refit the rear
Allen screw. Tighten the screw properly.
Rear Allen screw
