9 - 4

Preparation

9.05 Threading the needle thread / Adjusting the needle thread tension

Fig. 9 - 05

Turn the machine off!

● Thread the machine as shown in Fig. 9-05.

● Adjust the needle thread tension by turning disk 1.
