7 - 4
Controls
110-007
110-006
Fig. 7 - 07
7.07 Stitch position adjustment lever
● To set the required stitch position adjust
the stitch position adjustment lever 1.
Position "A" = stitch positioned to the left
Position "O" = stitch positioned in the centre
Position "B" = stitch positioned to the right
Fig. 7 - 08
7.08 Reverse feed control key / limiting the stitch length for reverse sewing
● As long as the reverse feed control key 1
is pressed, the machine sews in reverse.
● By turning screw 2, the stitch length for
reverse sewing is limited.
0
B
A
1
2
1
