10 - 3
Care and maintenance
110-053
10.04.02 Oiling points in the arm cover and bed plate
Fig. 10 - 04
Switch off the machine!
Danger of injury due to unintentional starting of the machine!
● Pour a few drops of oil once a week into the holes marked, see arrows in Fig. 10-04.
Only use oil with a mean viscosity of 22.0 mm
2
/s at 40°C and a density of
0.865 g/cm
3
at 15°C.
We recommend PFAFF sewing machine oil, part no. 280-1-120 144.
