9 - 2
Preparation
9.02 Winding the bobbin thread
● Place empty bobbin 1 on bobbin winder spindle 2.
● Thread the thread as shown in Fig. 9.02 and wind it around bobbin 1 a few times in a
clockwise direction.
● Set the preliminary thread tension by turning milled screw 3.
● Press lever 4 in the direction of the arrow until it clicks into place.
The bobbin is filled during sewing. If the bobbin is filled outside the sewing
operation, the balance wheel can be released by turning knob 5, so that the
needle bar does not move during the winding process.
Setting the amount of thread wound on the bobbin:
● Loosen screw 6.
● Turn lever 4 so that the bobbin switches off automatically when the thread is still approx.
1 mm from the edge of the bobbin.
● Tighten screw 6.
Fig. 9 - 02
110-016
5
1
2
4
3
1 mm
6
