Adjustment
12 - 13
12.05.11 Presser foot height
Requirement
At the bottom of its stroke, the presser foot should be at a distance of approx. 1 mm from
the needle plate.
Fig. 12 - 12
● Adjust presser foot 1 (screw 2) in accordance with the requirement.
For very thick materials the distance from the needle plate can be increased to
reduce the operating noise of the machine.
-
96-029
2
1
96-039
1 mm
