GAUGE FOR THE AFTER-SALES SERVICE G3
22.6
Dimension Use
Gauge No. 11691 For the adjustment of setting position of
EN-Sensor (measuring the clearance
between out side of a projected arc of slit-
plate and the bottom of U shaped part of
EN-Sensor ) Ref.to Page 22a & b
Dimension Use
Gauge No. 11692 For the adjustment of setting position of the
slit-plate. Ref. to Page 22a & b.
8.116
20
25
Thickness = 0.2mm
4.5
To Next Page
