7
For USA and Canada
This appliance has a polarized plug (one
blade wider than the other).
To reduce the risk of electric shock, it is
designed to fi t into a polarized outlet only
one way. If the plug does not fi t correctly into
the outlet, reverse the plug. If it still does not
fi t, contact a qualifi ed electrician to install the
proper outlet.
Do not modify the plug in any way.
Foot controller type 4C-325G - 230V / 4C-335B
- 110-125V / 4C-335G - 220 - 240V/
YC-482M - 110-125V / YC-483-5 - 230V.
has to be used with this overlock machine.
Connecting the foot control
Connect the plug of the foot control to the
connection socket 39 of the machine. The
sewing speed is regulated by activating
the foot control.
Electrical connection
Connect the foot control cord with the wall
outlet.
Master switch
When you turn on the master switch 38 the
sewing lamp is illuminated. The machine is
now operational.
