Parts of your select sewing machine
1 Connection socket “foot control with main cord”
2 Main switch
3 Handwheel release disk
4 Handwheel
5 Bobbin winder
6 Lid with stitches
7 Extra spool holder
8 Spool holder with spool cap
9 Take-up lever
10 Needle thread tension dial
11 Threading path
12 Thread cutter
13 Needle threader (1540)
14 Presser foot holder with presser foot
15 Removable accessory tray
16 Base plate
17 IDT System / Integrated Dual Feed (1540/1530)
18 Needle holder with fi xing screw
19 Presser foot lifter
20 Button for “reverse sewing”
21 Stitch length dial
22 Stitch selection 1540
23 Carrying handle
24 Stitch selection 1530 & 1520
25 Thread guide
26 Sewing lamp (max. 15 watt)
27 Stitch width dial
28 Needle position dial
29 Needle plate
