Operating Manual | Attachment and Installation Cooling Units | Standard Controller (SC) – 230 V | 086100113 23/66
3.7.2 Electrical data
Designation Unit Model DTI / DTS 6201
Rated voltage */** V 230 V, 1~
Rated frequency * Hz 50/60
Functional area — DIN IEC 60038
Power consumption * A35 / A35 P
el
50 Hz W 500
P
el
60 Hz W 631
Power consumption * A50 / A35 P
el
50 Hz W 573
P
el
60 Hz W 733
Nominal current * I
nom
50 Hz A 3.1
I
nom
60 Hz A 4.8
Start-up current * I
Start max
50 Hz A 9.1
I
Start max
60 Hz A 9.1
MOP (Maximum Overcurrent Protection)*** A 15.0
MCA (Minimum Circuit Ampacity)*** A 5.5
Tab. 7: Electrical data model DTI / DTS 6201
Designation Unit Model DTI / DTS 6301
Rated voltage */** V 230 V, 1~
Rated frequency * Hz 50/60
Functional area — DIN IEC 60038
Power consumption * A35 / A35 P
el
50 Hz W 721
P
el
60 Hz W 845
Power consumption * A50 / A35 P
el
50 Hz W 831
P
el
60 Hz W 945
Nominal current * I
nom
50 Hz A 5.0
I
nom
60 Hz A 4.4
Start-up current * I
Start max
50 Hz A 19.7
I
Start max
60 Hz A 19.7
MOP (Maximum Overcurrent Protection)*** A 15.0
MCA (Minimum Circuit Ampacity)*** A 6.5
Tab. 8: Electrical data model DTI / DTS 6301
* Data on the type plate.
** In case the rated voltage changes, adapt the upstream fuse, see "Adapting the unit to the mains voltage", Page 45.
*** Data for UL-approved units on the design of the protection (MOP) and cable cross-sections (MCA).
