Operating Manual | Attachment and Installation Cooling Units | Standard Controller (SC) – 400 V, 2~ | 086100115 23/68
3.7.2 Electrical data
Designation Unit Model DTI / DTS 6201
Rated voltage */** 50 Hz V 400 V, 2~
60 Hz V 460 V, 2~
Rated frequency * Hz 50/60
Functional area — DIN IEC 60038
Power consumption * A35 / A35 P
el
50 Hz W 532
P
el
60 Hz W 653
Power consumption * A50 / A35 P
el
50 Hz W 607
P
el
60 Hz W 746
Nominal current * I
nom
50 Hz A 2.4
I
nom
60 Hz A 2.5
Start-up current * I
Start max
50 Hz A 5.5
I
Start max
60 Hz A 5.5
MOP (Maximum Overcurrent Protection)*** A 15.0
MCA (Minimum Circuit Ampacity)*** A 3.3
Internal control fuse for transformer. Category
“Class CC”, slow-blow, suitable for transformer
protection.
F2, F3 A 4.0
Tab. 7: Electrical data model DTI / DTS 6201
Designation Unit Model DTI / DTS 6301
Rated voltage */** 50 Hz V 400 V, 2~
60 Hz V 460 V, 2~
Rated frequency * Hz 50/60
Functional area — DIN IEC 60038
Power consumption * A35 / A35 P
el
50 Hz W 778
P
el
60 Hz W 874
Power consumption * A50 / A35 P
el
50 Hz W 865
P
el
60 Hz W 961
Nominal current * I
nom
50 Hz A 3.7
I
nom
60 Hz A 2.4
Start-up current * I
Start max
50 Hz A 12.0
I
Start max
60 Hz A 12.0
MOP (Maximum Overcurrent Protection)*** A 15.0
MCA (Minimum Circuit Ampacity)*** A 3.9
Internal control fuse for transformer. Category
“Class CC”, slow-blow, suitable for transformer
protection.
F2, F3 A 6.25
Tab. 8: Electrical data model DTI / DTS 6301
* Data on the type plate.
** In case the rated voltage changes, adapt the upstream fuse, see "Adapting the unit to the mains voltage", Page 45.
*** Data for UL-approved units on the design of the protection (MOP) and cable cross-sections (MCA).
