Operating Manual | Attachment and Installation Cooling Units | Standard Controller (SC) – 230 V | 086100113 24/66
3.7.3 Dimensions
Designation Unit Model DTI / DTS 6201
Height mm DTI: 1537
DTS: 1540
Width mm 485
Depth with cover (standard) mm 218
Installation depth DTI mm 60
Weight kg DTI: 55
DTS: 58
Installation attitude — Vertical
Unit construction — Standard: Steel sheet
Option: With stainless-steel cover
Tab. 9: Dimensions and weight model DTI / DTS 6201
Designation Unit Model DTI / DTS 6301
Height mm DTI: 1537
DTS: 1540
Width mm 485
Depth with cover (standard) mm 218
Installation depth DTI mm 60
Weight kg DTI: 55
DTS: 58
Installation attitude — Vertical
Unit construction — Standard: Steel sheet
Option: With stainless-steel cover
Tab. 10: Dimensions and weight model DTI / DTS 6301
3.7.4 Other unit data
Designation
Anti-corrosion protection Standard: Galvanized, electrostatically powder-
coated (200°C)
Variant: Stainless-steel cover (material 1.4301, grounded)
Housing protection type (according to EN 60529) When used as intended:
• IP 55 internal – against the switch cabinet.
• IP 24 internal – against the environment.
