Safety
10 | 40 Operating instructions Sortimat | Edition 1
2.1.3 Safety spring on the sieve stack
The sieve stack on the SORTIMAT has a built-in safety spring as a locking unit so that the sieve stack does
not tip backwards after installation.
Figure 1: Position of safety spring during operation Figure 2: Position of safety spring when sieve stack is set up
CAUTION
Bruises and cuts on hands and fingers!
 Make sure that the safety spring is always in the correct installation position.
 Loosen the safety spring by pressing downwards.
 Replace the safety spring immediately if it is bent or if the pressure is too easy to
loose. Article number see chapter 10.
Test
Interval
Method
d
F
