Spare and wearing parts
34 | 40 Operating instructions Sortimat | Edition 1
10 Spare and wearing parts
NOTE
We wish to point out expressly that replacement and accessory parts not supplied by
us will not have been tested and approved by us either. Installing and/or using such
products can thus result in the design properties of the SORTIMAT being negatively
impaired.
Pfeuffer GmbH cannot be held liable for damage attributable to the use of non-
genuine parts and non-genuine accessories.
Standard parts can be obtained from the dealer.
Figure 16: SORTIMAT spare parts
Item
Spare part
Article no.
1
Drawer K3
3111 0004
Drawer K4
3111 0104
Drawer K5
3111 0204
2
Collecting tray (K3 = 4x, K4 = 5x, K5 = 6x)
2440 0019
not illustr.
Collecting tray for malt
2440 0022
3
Slide K3
3111 0007
Slide K4
3111 0107
8
13
14
3
4
5
6
7
9
10
11
12
2
1
15
16
