Pfeuffer Sortimat K3 User Manual

Spare and wearing parts
Edition 1 | Operating instructions Sortimat 35 | 40
Item
Spare part
Article no.
Slide K5
3111 0207
4
Brass knob
3134 0001
5
Cover, complete
2440 0160
6
Holding screw K3, complete
2440 0145
Holding screw K4, complete
2440 0146
Holding screw K5, complete
2440 0147
7
Sieve cleaning device, complete
(detailed illustration see chapter 8.2.3)
2440 0170
Spring bracket, outer
3125 0065
Spring bracket, inner
3125 0060
Rubber roller
2440 0172
Wheel
3121 0020
8
Securing hook K3
3125 0040
Securing hook K4
3125 0041
Securing hook K5
3125 0042
9
Pull handle K3
3160 2400
Pull handle K4
3160 2402
Pull handle K5
3160 2404
10
Stop (spacer) (K3 = 1x, K4 + K5 = 2x)
3160 2401
Cushioning disk (K3 = 2x, K4 + K5 = 4x)
3135 2400
11
Sieve frame, complete
2440 0150
12
Tilting frame, complete
2440 0150
13
Spring for locking unit
3125 2010
+ fillister head screw M3
3100 2025
+ plain washer M3
3102 1003
14
Grub screw M5 (K3, K4)
3170 2474
+ hexagon nut M5
3101 0015
Grub screw M5 (K5)
3170 2475
+ hexagon nut M5
3101 0015
15
Calibrating screw (fillister head screw) M4
3100 2060
+ hexagon nut M4
3101 0010
16
Suction foot
3135 0010
not illustr.
Glass microfuse 1 A slow-blow, 5 x 20 mm (10x)
3253 0216
not illustr.
Support springs, 1 set
3125 0051
not illustr.
Timer, complete
2440 0310
NOTE
Repair and renewal work on the motor should only be carried out by a specialist! Please
contact Pfeuffer GmbH if you have any questions.
