6
2. EXPLODED VIEW
1. Chassis
2. Top Panel
3. SSD Bracket
4. ODD Bracket
5. Right Side Panel
6. Front Panel
7. HDD Tray
8. Hard Drive Cage
9. Front Mesh cover
10. Window Left Side Panel
11. Mid-plate Bracket
12. Rear Dust Filters
13. Radiator Bracket
14. Top Dust Filter
1
2
7
6
5
10
3
9
8
12
13
4
11
14
