Phanteks NV7 - Exploded View

6 7
LIGHTING EFFECTS
The Digital-RGB lighting can be easily
controlled with the 4 buttons on top of
the chassis:
EXPLODED VIEW
PARTS
1 Chassis
2 Front glass panel
3 Right side mesh panel
4 Left glass panel
5 Top panel
6 Bottom fan bracket
7 Side fan bracket
8 Rear door
9 Bottom dust lter
10 Front I/O
11 GPU Support Bracket
12 Motherboard Cover
13 D-RGB Cover
14 Top I/O
15 Rear Mesh Cover
16 Airow Cover
15
04
01
16
13
12
11
08
10
09
06
05
03
07
14
MODES
Solid
Rainbow
Breathing
Pixelate
Wave
Two-Tone
Fade
BLUEYELLOW TEALORANGEMAGENTA
LIGHT
BLUE
GOLDPINK GREENREDWHITE
Press and hold the MODE button for two seconds to turn off LEDs,
press again to turn it ON
TURN OFF LEDs
SPEED
COLOR
MODE
CHANNEL SWITCH A/B
02
