Phanteks NV7 User Manual

14 15
POWER SUPPLY INSTALLATION
01
INSERT PSU
Insert the PSU from the right side of the chassis.
02
SECURE PSU
Secure the PSU from the rear with 4x PSU
screws.
Attach all PSU cables rst before
installing the PSU into the chassis.
PRO TIP
PSU SCREW 4x
INSTALL
RADIATOR & FAN POSITIONS
RADIATOR POSITIONS FAN POSITIONS
up to 360
up to 360
up to 280
up to 240
up to 360
120
120
120
120
120
120
120
120
120
120
120
120
140140140
Side: up to 360 Top: up to 360
Bottom: up to 360/280 Rear: up to 240
Side: 4x 120 mm Top: 3x 120 mm
Bottom: 3x 120/140 mm Rear: 2x 120 mm

Phanteks NV7 Specifications

General

Type	Mid Tower
Motherboard Support	E-ATX, ATX, Micro-ATX, Mini-ITX
Material	Steel, Tempered Glass
Expansion Slots	7
PSU Support	ATX
Maximum CPU Cooler Height	185 mm
Radiator Support - Top	Up to 360 mm
Radiator Support - Side	Up to 360 mm
Radiator Support - Bottom	Up to 360 mm
Radiator Support - Rear	120mm
Fan Support - Rear	1x 120 mm
Drive Bays	2 x 3.5", 4 x 2.5"
Front I/O Ports	2 x USB 3.0, 1 x USB Type-C, Audio In/Out
Fan Support - Top	3x 120 mm
Fan Support - Bottom	3x 120 mm
Maximum GPU Length	450 mm
Fan Support - Side	3 x 120 mm
