POWER BUTTON AND LED
Connect the power switch module to
the motherboard.
power switch/power LED module
motherboard header diagram
power switchpower LED
01
CONNECT POWER BUTTON
POWER_SW
FAN & RADIATOR INSTALLATION
Up to 3x 120 fans/360 radiator can be
directly installed into the top of the
chassis.
Fan cables can be routed through the
cut-outs on the top.
TOP FAN/RADIATOR POSITION
01
INSTALL FANS/RADIATOR
routing cut-out
