Phanteks NV7 User Manual

8 9
ACCESSORIES
GPU SUPPORT BRACKET
Included in accessory box
SCREWS OTHER ACCESSORIES
1x D-RGB Motherboard adapter cable
1x Microber Cloth
6x Zipties
1x Manual
AIRFLOW COVER
2x Included in accessory box
SPECIFICATIONS
CASE SPECIFICATIONS
Dimension (DxWxH) 532 x 253 x 586 mm / 20.9 x 10.0 x 23.1 in
Form Factor Full Tower
Materials Steel, Tempered Glass front and side panels
Motherboard Support
ATX, micro-ATX, mini-ITX, E-ATX (up to 277 mm
wide), SSI-CEB (up to 290 mm w/o cover )
Front I/O
Power switch, 1x USB 3.2 Gen2 Type-C, 2x USB 3.0,
D-RGB Mode, D-RGB Color, D-RGB Speed, D-RGB
Channel, Microphone/Headphone
PCI SLOTS & DRIVE BAYS
PCI Slots 8x
Internal 2.5” 6x
Internal 3.5” 2x
FAN 120mm 140mm
Side 4x -
Top 3x -
Bottom 3x 3x
Rear 2x -
RADIATOR 120mm 140mm
Side up to 360 -
Top up to 360 -
Bottom up to 360 up to 280
Rear up to 240 -
INCLUDED ACCESSORIES
GPU Support Bracket 1x
Airow Cover 2x
Toolbox 1x
CLEARANCE
GPU Length 450 mm / 17.7 in
CPU Cooler Height 185 mm / 7.3 in
PSU Length 255 mm / 10.0 in
Side 360 Radiator Maximum size: 132 x 440 mm
Side 360 Radiator Thickness 65 mm (to GPU)
Top 360 Radiator Maximum size: 132 x 440 mm
Rear 240 Radiator Maximum size: 132 x 320 mm
SSD + MOTHERBOARD
SCREW
34X
ANTI-SAG BRACKET
THUMB SCREW
4X
EXTRA RIGHT SIDE
PANEL SCREW
1X
STAND-OFF REMOVAL
TOOL
1X
MOTHERBOARD
STAND-OFF
1X
PSU SCREW
34X
HDD LOCKING SCREW
9X

Phanteks NV7 Specifications

General

Type	Mid Tower
Motherboard Support	E-ATX, ATX, Micro-ATX, Mini-ITX
Material	Steel, Tempered Glass
Expansion Slots	7
PSU Support	ATX
Maximum CPU Cooler Height	185 mm
Radiator Support - Top	Up to 360 mm
Radiator Support - Side	Up to 360 mm
Radiator Support - Bottom	Up to 360 mm
Radiator Support - Rear	120mm
Fan Support - Rear	1x 120 mm
Drive Bays	2 x 3.5", 4 x 2.5"
Front I/O Ports	2 x USB 3.0, 1 x USB Type-C, Audio In/Out
Fan Support - Top	3x 120 mm
Fan Support - Bottom	3x 120 mm
Maximum GPU Length	450 mm
Fan Support - Side	3 x 120 mm
