RATINGS
Product Specifications
Table 1 – General Specifications
ES3R
HP
1/3 - 2
Motor Style
2-Wire or 3-Wire
Nominal Input Voltage
120/240 VAC
Input Voltage Range
96 – 132 VAC
190 – 265 VAC
Max. Input Current
24 A
Output Voltage
Equal to Input
Max. Output Current
13.1 A
Output Power
2 kW
Enclosure Type
NEMA 3R
Operating Temperature
1/3 HP to 1-1/2 HP -20 °C to 50 °C (-4 °F to 122 °F)
2 HP -20 °C to 40 °C (-4 °F to 104 °F)
Storage Temperature
-13 °F – 165 °F
(-25 °C – 74 °C)
Dimensions (H x W x D)*
12.25 in x 9.25 in x 4.68 in
Weight
7 lbs
* Detailed dimensions on next page.
Essential Series drives are capable of operating several types of systems, including:
• Simple ON/OFF motor control from the keypad or remote switches
• Digital constant pressure water systems
• Analog constant pressure water systems
• Analog speed potentiometer controlled systems
• Pump Up or Pump Down water systems
The drive contains a wide range of settings and parameters allowing the user to easily
configure the drive for many applications. Detailed information on setting System
Configuration can be found in Section 6.5, on page 32.
