ADJUSTABLE PARAMETERS
5.1 Changing Parameter Values
WARNING: When the drive is set to automatically restart after a fault, the output
terminals can energize and the load can start without warning, exposing the user to risk of
serious injury. Make certain the input is de-energized before approaching the equipment.
The default setting ENABLE RESTARTS allows the unit to automatically restart after
certain faults. To disable this parameter, see Table 15.
The Change Parameter Values function allows the user to set values for a variety of
functions including motor overload settings, number of restarts after a fault, ramp time,
maximum frequency, and more. To change parameter values:
1. Use the keypad to navigate to CHANGE PARAMETER VALUES in the menu.
2. Press ENTER to access this menu item.
3. There are multiple sub-menu items under CHANGE PARAMETER VALUES.
Use the up and down arrows to scroll through the sub-menu to find the item
desired, and then press ENTER. See Table 12 through Table 15, for a list of
parameters with a description.
4. Use the up and down arrow keys to scroll to the parameter you want to set, press
ENTER, then use the up and down arrows to select a new value for that
parameter.
5. When the value you want appears on the display, press ENTER to select that
value.
6. To escape the parameter without selecting or resetting the value, press the
BACK key, which will return you to the list of parameters.
Programming Tip
Press the ENTER key to move to lower levels of the menu outline or to save a new
parameter value. Press the BACK key to move to higher levels in the menu outline or to
escape a parameter setting without changing the value.
