27 | P a g e
DISPLAY
MESSAGE
DESCRIPTION
DEFAULT/MIN
/MAX VALUE
PASSWORD
SETUP
Allows keypad to be password protected. When
keypad is locked, parameters and values can be
viewed but not changed. Parameter value of zero
disables password protection. Use arrows to scroll to
a value that will become the password.
0000/
0000/
9999
PROGRAM
RELAY
This setting is reserved for larger systems with
relays provided by factory. Not applicable for ES3R.
N/A
ANALOG IN
REVERSE
(YES=Pump
Down)
Reverses the scale of the analog signal, both 0-
5VDC and 4-20mA. For example, in normal 0-5VDC
signal, 0V = low and 5V = high. In reverse, 5V = low
and 0V = high.
NO = normal, YES = reverse
NO/YES
DISABLE
MANUAL MODE
Disables manual operation of the drive through the
keypad. Operating states are limited to AUTO and
OFF. YES = MANUAL mode disabled
YES/NO/YES
AUX1 SELECT
Programmable digital input. Generally used for motor
Run/Stop control.
0 = RUN/STOP (closed = RUN, open = STOP)
1 = RUN/STOP (closed = STOP, open = RUN)
2 = Always in RUN mode (no jumper or switch
required)
Default:
0/0/2
If SYSTEM
CONFIG = 2
(Analog CP):
1/0/2
AUX2 SELECT
Programmable digital input. Generally used for motor
Run/Stop control.
0 = RUN/STOP (closed = RUN, open = STOP)
1 = RUN/STOP (closed = STOP, open = RUN)
2 = Always in RUN mode (no jumper or switch
required)
Function of these inputs can change when certain
System Configuration settings are chosen.
See Section 6.5 for additional info.
1/0/2
LCD Contrast
Used to adjust the contrast and readability of the
graphic display.
40/30/63
Table 15 – Auto-Restart Parameters
DISPLAY
MESSAGE
DESCRIPTION
DEFAULT/MIN
/MAX VALUE
ENABLE
RESTARTS
Controls the ability of the drive to automatically
restart after a fault and to initialize in AUTO mode.
NO = no auto restarts and unit will initialize in OFF
mode
YES = Auto mode on initialization and auto restarts
allowed
Default is YES
DRY WELL
DELAY
Time in seconds dry well is allowed before unit trips
4/0/9999
