SECTION 15: HC-75C (600V) PARTS LIST
Qty
Phenix Part #
Item
Description
CONTROLLER
4
1001402
CABLE 101-104
RIGHT ANGLE USB CABLE, 2’
3
1079908
CABLE 105-107
RIBBON CABLE
5
1152145
CABLE
37 PIN TO RIBBON
1
1152160
CABLE
40 PIN CONN
1
1152248
CON
3CKT
1
1152590
CON1
POWER INPUT MODULE
1
1152270
CON10
CON 6CKT
2
1152271
CON2
CON 6CKT
2
1152200
CON5
CON 2CKT
1
1152683
CON6
PLUG 2 POS
2
1152210
CON7
CON 10CKT
4
1152230
CON8-9
CON 12CKT
2
1001818
DAQ1-2
24 CH DIGITAL I/O BD
1
1001819
DAQ3
16BIT MULTIFUNC
1
1603602
F101
FUSE
1
1001732
HC CBL
PVC CBL 10’
1
1077167
PWR
PWR CORD
2
1152623
J1
PLUG 3 POS
4
1151627
J3-4
PLUG 4 POS
2
1152668
J6
PLUG 10 POS
2
1152633
J7
PLUG 6 POS
1
1153973
J9
MOLEX RCPT
2
1153974
J9
MOLEX CONN FEM
1
1153910
LP1
MLX PLG
2
1153915
LP1
MOLEX F PIN
1
1153930
LP1
MLX RCPT
2
1153935
LP1
MLX M PIN
1
1420122
LP1
LED PANEL MNT
1
1001986
PC CBL
CABLE
1
1590158
PS101
PWR SUPPLY
1
1001391
USB
CONN PANEL MNT
1
1001395
USB
SEALING CAP
1
1001415
USB HUB
4 PORT USB HUB
1
31138901
PCB1389
HC INTERFACE BD
1
31139100
PCB1391
HC INTERCONNECT BD
