Phenix Technologies HC-75C User Manual

HC 75C
15-2
HC-75C (600V) PARTS LIST
Qty
Phenix Part #
Item
Description
REGULATOR AND HIGH CURRENT SECTION
1
38602282
T301
TRANSFORMER, HIGH CURRENT
2
1356214
BP201,3
BINDING POST, BLACK
2
1356215
BP202,4
BINDING POST, RED
1
1092590
C201
CAPACITOR
1
1099120
C202
CAPACITOR
1
1600609
CB201
CIRCUIT BREAKER
1
1600751
CB202
CIRCUIT BREAKER
1
30030007
CBL201/CON101
RIBBON CABLE ASSEMBLY
1
1152903
CON201
RECEPTACLE, FEMALE, GREEN
1
1152906
CON201
PLUG, GREEN
2
1152902
CON202, CON203
RECEPTACLE
2
1152910
CON202, CON203
PLUG
1
1506560
CT201
COIL FOR CURRENT METER
10
1780025
D201-D210
DIODE
2
1603667
F201, F202
FUSE
2
1603921
F201, F202
FUSE HOLDER, 600V, 2 POLE
1
1603610
F203
FUSE, FAST ACTING
1
1603920
F203
FUSE HOLDER, 3AG PANEL MOUNT
1
1603605
F204
FUSE, FAST ACTING
1
1603910
F204
FUSE HOLDER, 3AG, SINGLE
5
2350125
FAN201- FAN205
FAN AND MOTOR
4
1705087
K201- K204
CONTACTOR, 24VDC COIL
6
1705094
K205- K210
CONTACTOR, 24VDC COIL
8
1701361
K211-214
KS201-204
RELAY
1
30180002
Leads-Continuity
HC CONTINUITY LEAD SET
1
1423265
LMP201
LAMP, NEON, 125V
6
1606150
MOV201-6
MOVISTOR
1
1606140
MOV207
MOVISTOR
1
1606100
MOV208
MOVISTOR
1
31115600
PCB201
TRIGGER BOARD, PCB1156
1
31115520
PCB202
INPUT/OUTPUT BOARD, PCB1155B
1
31125210
PCB203
RMS TO DC, PCB1252
1
1590295
PS201
POWER SUPPLY, 24VDC
2
1714010
R201, R202
RESISTOR
1
1740201
R203
RESISTOR
1
1761055
R204
POTENTIOMETER
1
1355315
R205
KNOB, 1” DIA.
1
1769998
R205
POTENTIOMETER
1
1740300
R206
RESISTOR
1
1763000
R207
THERMISTOR
1
1159922
RCP101
OUTLET, DUPLEX 120V, 15A
1
1808210
SCR201, SCR202
SCR ASSY
1
1565225
SCRC201
SCR CONTROLLER
1
1863360
SW201
SWITCH
