Philips 19B4LPCS/00 - Page 13

19B4LP LCD
13
4 Remove all the Tapes on
each cableˈRemove the
Mylar
5 Disassembly the USB
Cover and release TX bd
Cable’s Connect and LED
bd Cable’s Connect
6 Unlock the FFC by using
two hands(see note).
Please carefully use
two hands(one
hand presses the
locking- latch of
FFC cable’s
housing, and at the
same time another
hand pulls out the
FFC cable.) for this
step to avoid from
deforming the
terminals of
positive-locking type
FFC cable.
The locking-latch
of FFC cable’s
