0.1 M4 19S4 / 19B4 19” 5:4 LCD Monitor
2011/11/10 PHILIPS 67 of 18
19 T.M.D.S. data0 shield
20 No Connect
21 No Connect
22 T.M.D.S clock shield
23 T.M.D.S. clock+
24 T.M.D.S. clock-
3.2 Timing requirement
Factory Preset mode definition:
1. Perfect FOS while presenting those timings.
2. Will specify those timing in User's Manual
Preset mode definition:
1. Need to support those timings.
2. Perfect FOS after auto adjustment.
User mode
1. Can save those timing that not in Preset mode and can be showed (not over scalar or
Panel spec.)
2. It needs to reserve the 10 timings space in memory size.
3.2.1 Mode storing capacity
Factory preset modes : Refer to Timing table
Preset modes : Refer to Timing table
User modes : Refer to Timing table
Timing pixel clock over H/W limitation do not support.
1. Factory preset modes and preset modes are defined in the enclosed timing table file
ŕŪŮŪůŨġŵŢţŭŦįŹŭŴ
3.3 OSD/Keypad functions
ITEM
1 OSD/keypad definition
ŎĵġŐŔŅġŃŶŵŵŰůġ
ťŦŧŪůŪŵŪŰůġŠġijıIJIJIJıIJ
Ĵ
Reset -
No : Exit
Yes : Auto adjustment for displaying timing mode
and recall factory preset
2 OSD Translation
ŐŔŅŠŔŵųŪůŨŠŎĵŠijıIJ
IJIJıijıįŹŭŴŹ
8 LANGUAGES, w/o Turkish.
