0.1 M4 19S4 / 19B4 19” 5:4 LCD Monitor
2011/11/10 PHILIPS 63 of 18
1 FOREWORD
This specification describes a multi-scan color TFT LCD monitor.
All optical characteristics are determined according to panel specification after warming up longer
than 30 minutes.
2PRODUCT PROFILE
2.1 EDID Header
19S4L
1 User visible strings on .inf file Philips 19SL (19inch LCD MONITOR 19S4L)
2 Manufacturer ID ( EDID data) PHL
3 Product ID, "xxxx" 4 codes MSB(byte 12): 08
LSB (byte 11): B6
4 maximum resolution 1280x1024
5 Horizontal Frequency Range 30~83 KHz
6 Vertical Frequency Range 56~76Hz
7 Monitor Name (13 characters max.) Philips 19SL
19B4L
1 User visible strings on .inf file Philips 19BL (19inch LCD MONITOR 19B4L)
2 Manufacturer ID ( EDID data) PHL
3 Product ID, "xxxx" 4 codes MSB(byte 12): 08
ġ LSB (byte 11): B7
4 maximum resolution 1280x1024
5 Horizontal Frequency Range 30~83 KHz
6 Vertical Frequency Range 56~76Hz
7 Monitor Name (13 characters max.) Philips 19BL
LCD
Suppliers offer panel specifications.
Panel incoming specification: Follow Philips’ specification.
WLED:
AUO
Type NR. : AUO M190EG02 V9
Resolution : 1280*1024
Outside dimensions : 396(H) * 324(V) * 10.9(D) mm(Typ.)
Pitch (mm) : 0.294mm * 0.294mm
Color pixel arrangement : 1280 horiz. by 1024 vert. Pixels. RGB stripe arrangement
