Connector type: D-Sub male with DDC2B pin assignments.
Blue connector thumb-operated jack screws
Pin assignments:
PIN No. SIGNAL
1Red
2 Green/ SOG
3Blue
4Sense (GND)
5Cable Detect (GND)
6Red GND
7 Green GND
8Blue GND
9 DDC +3.3V or +5V
10 Logic GND
11 Sense (GND)
12 Bi-directional data
13 H/H+V sync
14 V-sync
15 Data clock
3.1.2 DVI Cable
The input signals are applied to the display through DVI-D cable.
Length : Please refer to cable bundle summary file
Connector type : DVI-D male with DDC-2B pin assignments
White connector thumb-operated jackscrews with transplant pin protective cover.
Pin Assignment:
Pin No. Description
1 T.M.D.S. data2-
2 T.M.D.S. data2+
3 T.M.D.S. data2 shield
4 No Connect
5 No Connect
6 DDC clock
7 DDC data
8 No Connect
9 T.M.D.S. data1-
10 T.M.D.S. data1+
11 T.M.D.S. data1 shield
12 No Connect
13 No Connect
14 +5V Power
15 Ground (for +5V)
16 Hot plug detect
17 T.M.D.S. data0-
18 T.M.D.S. data0+
To Next Page
