68 19B4LP LCD
ġ
3Power On logo
őũŪŭŪűŴŠōŰŨŰŠIJĺijıŹ
IJıĹıįţŮű
Power On Logo:
Power On Show up Philips logo 3 seconds
Æ Change to input signal.
This picture is reference only. The official drawing
will send out by PM.
3.4 Horizontal scanning
Sync polarity : Positive or Negative
Scanning frequency : 30 – 83 K Hz
3.5 Vertical scanning
Sync polarity : Positive or Negative
Scanning frequency : 50 -76Hz
3.6 Power input connection
Power cord length : please refer to M4 cable bundle summary file
Power cord type : 3 leads power cord with protective earth plug.
3.7 Power management
The monitor must comply with the Microsoft On Now specification, and meet EPA requirements.
Mode HSYNC VSYNC Video Pwr-cons. Indication Rec. time
Power-On On On Active
19S4L, 19S4LC <30W (max.)
19S4LA, 19B4LP <40W (max.)
EPA5.0 < 23.58W
White LED --
Standby Off Off Blanked < 0.2W
Blinking white LED
Period 1sec on
3sec off
< 3 s
DC Power Off N/A < 0.2W LED Off
3.8 VGA Display identification
In accordance with VESA Display Channel Standard Ver.1.0 and DDC 2B capability
3.9 DVI Display identification
In accordance with DVI requirement (DDWG digital Visual Interface revision 1.0) use DDC-2B,
DDC/CI, and EDID V1.3.
