Philips 43PUT6801 - 4.4 Assembly;Panel Removal (for 6801 series)

Mechanical Instructions
EN 18 QM16.3A LA4.
2016-Jun-08
Table 2-1
4.4 Assembly/Panel Removal (for 6801 series)
Instructions below apply to the 49PUT6801/98, but will be
similar for other 43"/49"/55"PUT6801 series models.
4.4.1 Stand
Refer to Figure 4-15
for details.
1. Remove the fixation screws [1] that secure the stand
bracket. Refer to Figure 4-15
for details.
2. Take the stand bracket out from the set.
Figure 4-15 Stand removal
20151_103.eps
1
1
1
1
