Philips 43PUT6801 - 4.5 Assembly;Panel Removal (for 7601 series)

Mechanical Instructions
EN 22 QM16.3A LA4.
2016-Jun-08
Table 2-1
4.5 Assembly/Panel Removal (for 7601 series)
Instructions below apply to the 65PUT7601/98, but will be
similar for other 65"PUT7601 series models.
4.5.1 Stand
Refer to Figure 4-21
for details.
1. Remove the fixation screws [1] that secure the stand
bracket. Refer to Figure 4-21
for details.
2. Take the stand bracket out from the set.
Figure 4-21 Stand removal
20152_102.eps
1
1
1
1
