Philips 49BDL3005X - Using of Edge Finishing Kit (Optional); Installing the Edge Finishing Kit

BDL4988XC/49BDL3005X
5
1.7. Using of Edge Finishing Kit (Optional)
Youcanusetheedgenishingkittoprotectthedisplayandhaveabetterappearance.
1.7.1. Installing the Edge Finishing Kit
InstallingEdgeFinishingKitfor1x1DisplayConguration
Edge Finishiing
Kit-Left(*1PC)
Edge Finishiing Kit-Top
(*1PC)
Edge Finishiing Kit-Bottom
(*1PC)
Screw
(QTY is different depending
on models)
Edge Finishiing
Kit-Right(*1PC)
Corner(*4PCS)
InstallingEdgeFinishingKitfor2x2DisplayConguration
Edge Finishiing Kit-Top
(*2PCS)
Edge Finishiing
Kit-Left(*2PCS)
Screw
(QTY is different depending
on models)
Edge Finishiing Kit-Bottom
(*2PCS)
Edge Finishiing
Kit-Right
(*2PCS)
Connector
(*4PCS)
Connector
(*4PCS)
*Seetheinstructionguideprovidedwiththekitfordetails.
