2.2. Input/Output Terminals
100-240V
50-60Hz 2.5A
HDMI 1 IN HDMI 2 IN
DP IN
RJ45
RS232
OUT
RS232
IN
HDMI 3 IN HDMI 4 IN
AUDIO IN
MICRO SD
IR-INIR-OUT
D-SUB
AUDIO OUT
USB
5V/2A
USB 2.0 USB 3.0
10
11
13
12
14
15
17
16
18
20
19
1 3
2
4
5 7
6 8 9
1
AC IN
ACpowerinputfromthewalloutlet.
2
MAIN POWER SWITCH
Switchthemainpoweron/off.
3
AC OUT
ACpowersupplytotheACINjackofamediaplayer.
4
RJ-45
LANcontrolfunctionfortheuseofremotecontrolsignalfrom
controlcenter.
5
RS232C IN /
6
RS232C OUT
RS232Cnetworkinput/outputfortheloop-throughfunction.
7
DisplayPort IN
DisplayPortvideoinput.
8
HDMI1 IN /
9
HDMI2 IN /
10
HDMI3 IN /
11
HDMI4 IN
HDMIvideo/audioinput.
12
IR OUT /
13
IR IN
IRsignalinput/outputfortheloop-throughfunction.
NOTES:
• Thisdisplay’sremotecontrolsensorwillstopworkingifthejack
[IRIN]isconnected.
• ToremotelycontrolyourA/Vdeviceviathisdisplay,refertopage
16fororIRPassThroughconnection.
14
VGA IN (D-Sub)
VGAvideoinput.
15
AUDIO IN
AudioinputforVGAsource(3.5mmstereophone).
16
AUDIO OUT
AudiooutputtoexternalAVdevice.
17
USB PORT
ConnectyourUSBstoragedevice
18
USB PORT A
USB
5V/2A
19
MICRO SD CARD
ConnectyourMICROSDCARD.
20
OPS SLOT
SlotforinstallingtheoptionalOPSmodule.
