GENERAL PRODUCT SPECIFICATION(Continued)
8639 000 15121
2003-12-19
2003-12-19
590
10
31
C.C.Liao
DELL P1230 M25P
22" CMTR-M25P-Dell-P1230
TYPE : 6L3P10/76
OEM : Dell P1230 130KHz
Go to cover page
MODE NO. 1 2 3 4
RESOLUTION 720 x 400 640 x 480 640 x 480 640 x 480
Dot clock(MHz) 28.321 25.175 31.500 36.000
f h 31.468 kHz 31.469 kHz 37.500 KHz 43.269 kHz
A ( us ) 31.778 31.778 26.667 23.111
B(us) 3.813 3.813 2.032 1.556
C(us) 1.907 1.907 3.810 2.222
D ( us ) 25.422 25.422 20.317 17.778
E(us) 0.636 0.636 0.508 1.556
f v 70.085 Hz 59.941 Hz 75.000 Hz 85.008 Hz
O (ms ) 14.268 16.683 13.333 11.764
P(ms) 0.064 0.064 0.080 0.069
Q(ms) 1.080 1.048 0.427 0.578
R ( ms ) 12.711 15.253 12.800 11.093
S(ms) 0.413 0.318 0.027 0.023
SYNC. H/V - /+ -/- -/- -/-
POLARITY
SEP . SYNC Y Y Y Y
MODE NO. 5 6 7 8
RESOLUTION 800 x 600 800 x 600 1024 x 768 1024 x 768
Dot clock(MHz) 49.500 56.250 65.000 78.750
f h 46.875 kHz 53.674 kHz 48.363 kHz 60.023 kHz
A ( us ) 21.333 18.631 20.677 16.660
B(us) 1.616 1.138 2.092 1.219
C(us) 3.232 2.702 2.462 2.235
D ( us ) 16.162 14.222 15.754 13.003
E(us) 0.323 0.569 0.369 0.203
f v 75.000 Hz 85.061 Hz 60.004 Hz 75.029 Hz
O (ms ) 13.333 11.756 16.666 13.328
P(ms) 0.064 0.056 0.124 0.050
Q(ms) 0.448 0.503 0.600 0.466
R ( ms ) 12.800 11.179 15.880 12.795
S(ms) 0.021 0.018 0.062 0.017
SYNC. H/V + / + +/+ -/- +/+
POLARITY
SEP . SYNC Y Y Y Y
