Philips DELLP1230 - Page 55

GENERAL PRODUCT SPECIFICATION(Continued)
8639 000 15121
2003-12-19
590
31
C.C.Liao
Go to cover page
202P Gs3 CM25
DELL P1230 M25P
55
22" CMTR-M25P-Dell-P1230
TYPE : 6L3P10/76
OEM : Dell 130KHz
11
MODE NO. 9 10 11 12
RESOLUTION 1024 x 768 1152 x 864 1152 x 864 1280 x 1024
Dot clock(MHz) 94.500 108.000 119.651 108.000
fh 68.677 kHz 67.5 kHz 77.095kHz 63.981 kHz
A(us) 14.561 14.815 12.971 15.630
B(us) 1.016 1.185 1.070 1.037
C(us) 2.201 2.37 1.672 2.296
D(us) 10.836 10.667 9.628 11.852
E(us) 0.508 0.593 0.602 0.445
fv 84.997 Hz 75 Hz 85Hz 60.020 Hz
O(ms) 11.765 13.333 11.765 16.661
P(ms) 0.044 0.044 0.039 0.047
Q(ms) 0.524 0.474 0.506 0.594
R(ms) 11.183 12.815 11.207 16.005
S(ms) 0.015 0.015 0.0123 0.015
SYNC. H/V +/+ +/+ -/+ +/+
POLARITY
SEP . SYNC Y YYY
MODE NO. 13 14 15 16
RESOLUTION 1280 x1024 1280 x 1024 1400 x 1050 1400 x 1050
Dot clock(MHz) 135.00 157.500 122.614 155.851
fh 79.976 kHz 91.146 kHz 65.220 kHz 82.200 kHz
A(us) 12.504 10.971 15.333 12.165
B(us) 1.067 1.016 1.240 0.975
C(us) 1.837 1.422 1.957 1.591
D(us) 9.481 8.127 11.418 8.983
E(us) 0.119 0.406 0.718 0.616
fv 75.025 Hz 85.024 Hz 60.000 Hz 75.000 Hz
O(ms) 13.329 11.761 16.667 13.333
P(ms) 0.038 0.033 0.046 0.037
Q(ms) 0.475 0.483 0.506 0.511
R(ms) 12.804 11.235 16.099 12.774
S(ms) 0.013 0.011 0.015 0.012
SYNC. H/V +/+ +/+ -/+ -/+
POLARITY
SEP . SYNC YYYY
