GENERAL PRODUCT SPECIFICATION(Continued)
8639 000 15121
2003-12-19
2003-12-19
590
12
31
C.C.Liao
DELL P1230 M25P
22" CMTR-M25P-Dell-P1230
TYPE : 6L3P10/76
OEM : Dell P1230 130KHz
Go to cover page
MODE NO. 17 18 19 20
RESOLUTION 1400 x 1050 1600 x 1200 1600 x 1200 1600 x 1200
Dot clock(MHz) 179.260 162 202.500 229.500
f h 93.755 kHz 75.000 kHz 93.750 kHz 106.250 kHz
A ( us ) 10.666 13.333 10. 667 9.412
B ( us ) 0.848 1.185 0. 948 0.837
C ( us ) 1.428 1.877 1. 501 1.325
D ( us ) 7.810 9.877 7.901 6.972
E ( us ) 0.580 0.395 0.316 0.279
f v 85.000 Hz 60.000 Hz 75.000 Hz 85.000 Hz
O (ms ) 11.765 16.667 13.333 11. 765
P ( ms ) 0.032 0.040 0.032 0.028
Q (ms ) 0.523 0.613 0.491 0.433
R ( ms ) 11.199 16.000 12.800 11.294
S ( ms ) 0.011 0.013 0.011 0.009
SYNC. H/V - / + + / + +/+ +/+
POLARITY
SEP . SYNC Y Y YY
MODE NO. 21 22 23 24
RESOLUTION 1280 x800 1280 x800 1280 x800 1600 x 1000
Dot clock(MHz) 107.214 123.379 147.891 169.128
f h 62.625 kHz 71.400 kHz 84.800 kHz 78.300 kHz
A ( us ) 15.968 14.006 11.792 12.771
B ( us ) 1.268 1.102 0.92 1.041
C ( us ) 2.015 1.816 1.569 1.656
D ( us ) 11.939 10.375 8.655 9.460
E ( us ) 0.746 0.713 0.649 0.615
f v 75.000Hz 85.000Hz 100.000Hz 75.000 Hz
O (ms ) 13.333 11.765 10.000 13.333
P ( ms ) 0.048 0.042 0.0354 0.038
Q (ms ) 0.495 0.504 0.519 0.511
R ( ms ) 12.774 11.204 9.434 12.771
S ( ms ) 0.016 0.014 0.012 0.013
SYNC.H/V -/+ -/+ -/+ -/+
POLARITY
SEP.SYNCYYYY
